Thank you for reading AF contactors

Always Future-ready

Four coils for the entire voltage range
The AF contactor features both AC and DC support. The total number of product variants compared to a conventional range is reduced by 90%. Only four coils are required to cover 24 V AC, 20 V DC – 500 V AC/DC.

Built-in surge suppression
With conventional contactor technology it is recommended to use an external surge suppressor, an accessory that could cost as much as half the contactor itself. With AF technology the surges are handled by the contactor itself. Neither the surge suppressor nor the actual surge has to be considered anymore. One less product and one less complication to worry about.

Wide control voltage range
With conventional contactor technology, different contactors were needed for different network voltages. Thanks to the wide operating range of the AF contactor it can operate just as well in Europe as in Asia or North America. The core coil of the AF contactor range covers 100-250 V AC/DC 50/60 Hz, making it ideal for exporting products to different territories.

Always Future-ready

Coil terminal access in the front
The AF contactor has its coil terminals accessible from the front. The cables or bars do not have to be disconnected in order to perform voltage measurement or servicing work.

More functionality without adding width
The AF116 … AF2650 can take up to 2 side mounted auxiliary contact blocks without adding to its width and are delivered with 1 N.O. + 1 N.C. as standard.

Easy-to-use accessories
Contactors up to 96 A offer free choice of coil terminal access and can take side and front mounted auxiliary contact blocks. All the accessories: Coil connection terminals, mechanical and electrical interlocks and electronic timers are easily connected through tool-free connection.

Safe control circuit with:

Mirror contact according to IEC 60947-4-1
Mechanically linked contacts according to IEC 60947-5-1
Sealable and transparent protective covers on AF09...AF96 and overload relays TF/EF
Third party certification: - AF09...AF96, NF - AF400...AF2050
